Heavy-duty CD series

Heavy-duty CD series

Cable drums

Cable drums

The Syntax® cable drums CD series has an extremely strong structure, thanks to high resistance bent and soldered structural steel tubes. External finish is high-resistance matt black powder.The crank handle can be lodged on the side of the external frame, making the cable drum a proper parallelepiped without any protrusion for space-saving in freight. Designed for professional application, the central roller presents an oversize 200 mm diameter which allows rewinding even large diameter cables, avoiding damage to the cables’ electrical and mechanical features. The drum is mounted on ball bearings and divided in two sections, the narrower of which is suited for housing cables’ ends. We also supply elastic band with velcro® ends, in order to avoid freight damage, binding the cables’ ends tight to the drum. On the side opposite to the crank, a friction-adjustable brake is installed, to stop the roller revolving during transport. Protective rubber feet on the bottom of the structure ensure the right ground-detachment and easier stacking.

Dimensions

Dimensions

Drum capacities summary table

Drum capacities summary table

CR series

CR series

Cable drums

Cable drums

This cable drum is easy to use and suitable for many different jobs and is particularly useful for the realization of multicore distribution system. Its perimetric structure completely clusters the drum. The high resistance frame, made up of bent and soldered structural steel, prevents accidental mechanical damage and is matt black powder coated. The internal diameter of the roller allows to easily wind/rewind either large cables or more delicate video and optical fiber cables.The central shaft of the steel roller is attached on one side only through a spindle fixed on a 40 mm boxed steel, while the other side is free. This drum side has a large opening where an optional quick-release plate can be set to house the cable ends. Alternatively, a 16, 24, or 32 hole drilled plate for XLR mounting can be fitted on the open side to obtain a revolving stage-box. The crank handle is located on the same side, while on the opposite side a friction-adjustable brake is supplied,  to stop the roller rotation during transport. The cable drum has four wheels (two of which with brakes), for easier moving.

Dimensions

Dimensions

Drum capacities summary table

Drum capacities summary table
